ITM Lifting Shoulder Eyebolt Din 580 - 12mm - 0.34T

TM9240-02120 | ITM Lifting Shoulder Eyebolt Din 580 - 12mm - 0.34T

Features
Galvanised finish
Specifications, batch and brand markings as per Australian Standards requirements
Tested and certified to AS 2317

Specifications
Thread: M12
W.L.L (t): 0.34
Dimension D (mm): 12
Dimension D1 (mm): 30
Dimension D2 (mm): 30
Dimension D3 (mm): 12
Dimension H (mm): 53
Dimension H1 (mm): 20.5
Dimension W (mm): 54
