ITM Lifting Shoulder Eyebolt Din 580 - 24mm - 1.8T

TM9240-02240 | ITM Lifting Shoulder Eyebolt Din 580 - 24mm - 1.8T

Features
Galvanised finish
Specifications, batch and brand markings as per Australian Standards requirements
Tested and certified to AS 2317

Specifications
Thread: M22
W.L.L (t): 1.5
Dimension D (mm): 22
Dimension D1 (mm): 40
Dimension D2 (mm): 40
Dimension D3 (mm): 16
Dimension H (mm): 71
Dimension H1 (mm): 30
Dimension W (mm): 72
